Flexible Ribbon Tape LED Strip (Non-Waterproof) 24W per Roll



TECHNICAL PARAMETERS:

Led Light Source: 3528 SMD
Standard: 300 LEDs per roll (16.25 feet)
Beam Angle: 120 degrees
Working Voltage: Regular 12VDC
Working Current: 400mA per meter (3.28 feet)
Power Consumption: 1.50 watts per foot (24watts per roll)
Led Light Output Per Roll: W:2100lm, NW:2000lm, WW:1800lm
Package: 16.25 feet per roll (5 meters)
Connection Length: 32.5ft per feed (2 rolls)
Connectors: WC2-8 / JC2-8 / CC2-8
Connectors RGB: WC4-10 / JC4-10 / CC4-10
Controllers for EX-RBL-RGB: RGB Controllers
Tracks: Compatible with All Tracks



LED drivers for the EX-RBL-XX and EX-UL-XX:

Dimmable:
EX-36W-12V-LED-DIM
EX-50W-12V-LED-DIM *SMALLEST DIMENSIONS*
EX-60W-12V-LED-DIM
EX-240W-12V-LED-DIM
EXM-60W-12V-LED-DIM
EXM-90W-12V-LED-DIM
EXM-150W-12V-LED-DIM
EXM-200W-12V-LED-DIM
EXM-300W-12V-LED-DIM

Non-dimmable:
LED-10W 12V DC
LED-25DC 12V/25W DC
LED-60DC 12V/60W DC
FL-60W-LED-PLUG-IN 12V/60W DC
LED-100DC 12V/100W DC

LED drivers for the EX-ETL-XX:

Dimmable:
EX-48W-24V-LED-DIM
EX-50W-24V-LED-DIM *SMALLEST DIMENSIONS*
EX-100W-24V-LED-DIM
EX-300W-24V-LED-DIM
EXM-90W-24V-LED-DIM
EXM-150W-24V-LED-DIM
EXM-200W-24V-LED-DIM
EXM-300W-24V-LED-DIM

Non-dimmable:
LED-10W 24V DC
LED-25W 24V DC
LED-60W 24V DC
LED-100W 24V DC



Ribbon Prices

1 to 4 - $99.00 ea.
5 to 14 - $94.00 ea.
15 or more - $89.00 ea.

EX-RBL$99.00, 5/$470.00, 15/$1,335.00


FREE SHIPPING!
ON ORDERS OF $75 OR MORE
(USPS or UPS Ground Residential)
$18 MINIMUM ORDER
